Product Details:
Payment & Shipping Terms:
|
| Condition: | New | Applicable Industries: | Manufacturing Plant, Food & Beverage Factory, Farms, Food Shop, Printing Shops, Energy & Mining, Slaughter House, Dairy Plant, Car Washing Plant |
|---|---|---|---|
| Showroom Location: | Egypt, Canada, Turkey, United Kingdom, United States, Italy, France, Germany, Viet Nam, Philippines, Brazil, Peru, Saudi Arabia, Indonesia, Pakistan, India, Mexico, Russia, Spain, Thailand, Morocco, Kenya, Argentina, South Korea, Chile, UAE, Colombia, Alge | Video Outgoing-inspection: | Provided |
| Machinery Test Report: | Provided | Marketing Type: | Hot Product 2023 |
| Warranty Of Core Components: | 1 Year | Core Components: | Pressure Vessel, Pump, Engine, Motor, PLC |
| Size: | 7600*2800*2260mm | Warranty: | 1 Year |
| Productivity: | 50L/Hour | Weight (KG): | 6350 Kg |
| Product Name: | Dissolved Air Flotation | Origin: | Shanghai |
| Dissolved Pump Power: | 5.5kw | Air Compressor Power: | 1.5kw |
| Skimmer Power: | 0.2kw | Coagulate Agitator Power: | 0.55kw |
| Flocculation Agitator Power: | 0.75kw | PH Agitator: | 0.75kw |
| Highlight: | Grease Wastewater Treatment Daf System,5.5kw Pump Daf Wastewater Treatment,5.5kw Pump Daf System |
||
Optimize Your Grease Wastewater Treatment Process with Dissolved Air Flotation System
DAF System Introduction
Dissolved Air Flotation is a water treatment process that clarifies wastewaters (or other waters) by the removal of suspended matter such as oil or solids.
The removal is achieved by dissolving air in the water or wastewater under pressure and then releasing the air atmospheric pressure in a flotation tank basin.
The released air forms tiny bubbles which adhere to the suspended matter causing the suspended matter to float to the surface of the water where it may then be removed by a skimming device.
DAF System Work Process
The wastewater enter RT1 (coagulation reaction tank) and RT2 (flocculation reaction tank) from the equalization tank through the lift pump, and coagulates with PAC floculates with (PAM) respectively form the flocs.
Then the wastewater and dissolved water enter the reaction zone of the DAF tank, and the microbubbles and flocs in the dissolved water are mixed and adhered to form solid particles ,which the density less than water, and float up to the surface of the DAF tank .
Under the action of buoyancy, scum is scraped to the slag tank. The clean water is collected down to the collect tank through the water collecting pipe, and most of the outer water is discharged (or into the next process), and a small part of the water is recirculated to form the dissolved water.
DAF System Features
1. Micro bubbles generating
2. Subsurface capture
3. Automatic slagging controlled by liquid level
4. Non-clogging releasing with high efficiency.
Application of DAF System
Municipal Sewage
Slaughter House
Metallurgical Industry Wastewater
Spraying Sewage
Printing & Dyeing Sewage
Metal-Processing Sewage
Mining Stone Wastewater
Electronic Sewage
How to select right model?
Wastewater type ( dairy wastewater , car washing wastewater ,slaughter house wastewater, food wastewater , river water …..)
SS content (ppm or mg/L)
Oil & Grease &Fat & FOG content (ppm or mg/L )
PH (6~9 is preferred . Otherwise consider PH adjust tank before DAF tank , also have to consider the material of the DAF because of Corrosive substance )
BOD (ppm or mg/L)
COD (ppm or mg/L)
DAF System for References
