5m3/h Electrocoagulation System for Wastewater Treatment 220V-480V

5m3/h Electrocoagulation System for Wastewater Treatment 220V-480V
5m3/h Electrocoagulation System for Wastewater Treatment 220V-480V 5m3/h Electrocoagulation System for Wastewater Treatment 220V-480V 5m3/h Electrocoagulation System for Wastewater Treatment 220V-480V 5m3/h Electrocoagulation System for Wastewater Treatment 220V-480V 5m3/h Electrocoagulation System for Wastewater Treatment 220V-480V 5m3/h Electrocoagulation System for Wastewater Treatment 220V-480V

Large Image :  5m3/h Electrocoagulation System for Wastewater Treatment 220V-480V

Product Details:
Place of Origin: Shanghai, China
Brand Name: ECOPRO
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: $36,897
Contact Now
Detailed Product Description
Productivity: 5m3/h Weight: 1900 Kg
Processing Type: Filtration Power: 1kW
Voltage: 220V, 380V, 110V Capacity: 5m3/h
Electrode Weight: 1900 Kg Empty Weight: 1900 Kg
Operation Weight: 7800 Kg Core Components: Motor
Power Supply Range: 220V-480VAC Anode Material: Aluminum, Iron
Current Adjustment: Automatic Voltage Adjustment: Automatic
Energy Saving Feature: No Polymer Required
Highlight:

electrocoagulation system for wastewater treatment

,

electrocoagulation system 220V

,

industrial electrocoagulation system with warranty

Electrocoagulation System 5m³/h for Wastewater Treatment
Product Specifications
Attribute Value
Productivity 5m³/h
Weight 1900 kg
Processing Type Filtration
Power 1kW
Voltage 220V, 380V, 110V
Power Supply Range 220V-480VAC
Anode Material Aluminum, Iron
Current Adjustment Automatic
Voltage Adjustment Automatic
Energy Saving Feature No polymer required
System Overview

The electrocoagulation system is an advanced wastewater treatment solution that utilizes metal hydroxide produced by soluble metal anodes during flocculation to effectively remove contaminants from water. The system employs aluminum, iron, and other cost-effective metals as anode materials.

Fabrication Process
5m3/h Electrocoagulation System for Wastewater Treatment 220V-480V 0 5m3/h Electrocoagulation System for Wastewater Treatment 220V-480V 1
Working Principle
5m3/h Electrocoagulation System for Wastewater Treatment 220V-480V 2 5m3/h Electrocoagulation System for Wastewater Treatment 220V-480V 3 5m3/h Electrocoagulation System for Wastewater Treatment 220V-480V 4
Electrochemical reaction: Fe→Fe²⁺+2e Anodizing reaction: 2OH⁻→2[O]+2e→O₂+2e Cathode reduction: 2H⁺+2e→2[H]→H₂

The system continuously performs oxidation and reduction functions on the plates, with nascent oxygen providing strong oxidation and nascent hydrogen breaking chemical bonds to reduce COD and chromophore functional groups.

Key Features
  • Wide power supply adaptability (220V-480VAC range)
  • Enhanced safety with embedded isolated voltage circuit and comprehensive protection systems
  • Automatic control system detects ion state and adjusts current/voltage accordingly
  • Energy efficient operation requiring no polymer additives
System Demonstration
5m3/h Electrocoagulation System for Wastewater Treatment 220V-480V 5
Reference Installation
5m3/h Electrocoagulation System for Wastewater Treatment 220V-480V 6 5m3/h Electrocoagulation System for Wastewater Treatment 220V-480V 7 5m3/h Electrocoagulation System for Wastewater Treatment 220V-480V 8 5m3/h Electrocoagulation System for Wastewater Treatment 220V-480V 9
Manufacturer Information
5m3/h Electrocoagulation System for Wastewater Treatment 220V-480V 10 5m3/h Electrocoagulation System for Wastewater Treatment 220V-480V 11 5m3/h Electrocoagulation System for Wastewater Treatment 220V-480V 12
