40m3/h Electrocoagulation System for Wastewater Treatment 3-30 kW

40m3/h Electrocoagulation System for Wastewater Treatment 3-30 kW
40m3/h Electrocoagulation System for Wastewater Treatment 3-30 kW 40m3/h Electrocoagulation System for Wastewater Treatment 3-30 kW 40m3/h Electrocoagulation System for Wastewater Treatment 3-30 kW 40m3/h Electrocoagulation System for Wastewater Treatment 3-30 kW 40m3/h Electrocoagulation System for Wastewater Treatment 3-30 kW 40m3/h Electrocoagulation System for Wastewater Treatment 3-30 kW

Large Image :  40m3/h Electrocoagulation System for Wastewater Treatment 3-30 kW

Product Details:
Place of Origin: Shanghai, China
Brand Name: ECOPRO
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: $38,627
Contact Now
Detailed Product Description
Productivity: 40m3/h Weight: 2298 Kg
Processing Type: Filtration Power: 3 KW, 30 KW, 20 KW
Voltage: 220 V, 380 V, 110 V Capacity: 40m3/h
Electrode Weight: 11500 Kg Empty Weight: 3500 Kg
Operation Weight: 31000 Kg Treating Capacity: 1m3/h
Power Consumption: 3kw/h Dimension: 1000*650*1500 Mm
Electrode Weight: 650 Kg Empty Weight: 400 Kg
Operation Weight: 1500 Kg
Highlight:

40m3/h electrocoagulation wastewater system

,

electrocoagulation system 3-30 kW

,

industrial wastewater treatment electrocoagulation

High Voltage Pulsed Electrocoagulation Equipment for Waste Water Treatment
Our electrocoagulation system is an advanced wastewater treatment solution that utilizes metal hydroxide produced by soluble metal anodes during flocculation to effectively remove contaminants from water. The system typically uses aluminum, iron, or other readily available metals as anode materials.
40m3/h Electrocoagulation System for Wastewater Treatment 3-30 kW 0 40m3/h Electrocoagulation System for Wastewater Treatment 3-30 kW 1
Technical Specifications
Parameter Value
Treating Capacity 1m³/h
Power Consumption 3kw/h
Dimension 1000×650×1500mm
Electrode Weight 650kg
Empty Weight 400kg
Operation Weight 1500kg
40m3/h Electrocoagulation System for Wastewater Treatment 3-30 kW 2 40m3/h Electrocoagulation System for Wastewater Treatment 3-30 kW 3 40m3/h Electrocoagulation System for Wastewater Treatment 3-30 kW 4 40m3/h Electrocoagulation System for Wastewater Treatment 3-30 kW 5
Electrocoagulation System Principle
Fe → Fe²⁺ + 2e
2OH⁻ → 2[O] + 2e → O₂ + 2e
2H⁺ + 2e → 2[H] → H₂
The electrochemical process generates nascent oxygen with strong oxidation capabilities similar to UV, H₂O₂, and O₃. Simultaneously, nascent hydrogen breaks chemical bonds, reduces COD, and degrades chromophore functional groups. These oxidation and reduction reactions continuously occur on the electrode plates.
System Features
  • Wide power supply adaptability: Operates within 220V-480VAC range
  • Safe and convenient: Embedded isolated voltage circuit ensures electrical safety with multiple protection mechanisms (phase loss, overload, overcurrent, overvoltage, zero voltage)
  • Automatic control: Detects ion state in water to automatically adjust current and voltage
  • Energy efficient: Utilizes Fe(OH)₂ and Fe(OH)₃ as natural coagulants, eliminating need for polymer additives
40m3/h Electrocoagulation System for Wastewater Treatment 3-30 kW 6 40m3/h Electrocoagulation System for Wastewater Treatment 3-30 kW 7
Manufacturer Information
Shanghai Ecopro Environmental Engineering Co., Ltd., established in 2017, specializes in comprehensive water and wastewater treatment equipment and separation services. As a professional environmental engineering company, we provide industry-leading equipment, services, and systematic solutions including static screens, rotary drum screens, polymer dosing systems, DAF systems, electrochemistry systems, screw presses, plate filter presses, sludge dryers, Mutag Biochips, sodium hypochlorite generators, and various pumps.
40m3/h Electrocoagulation System for Wastewater Treatment 3-30 kW 8 40m3/h Electrocoagulation System for Wastewater Treatment 3-30 kW 9 40m3/h Electrocoagulation System for Wastewater Treatment 3-30 kW 10 40m3/h Electrocoagulation System for Wastewater Treatment 3-30 kW 11 40m3/h Electrocoagulation System for Wastewater Treatment 3-30 kW 12 40m3/h Electrocoagulation System for Wastewater Treatment 3-30 kW 13
Product Packaging
40m3/h Electrocoagulation System for Wastewater Treatment 3-30 kW 14 40m3/h Electrocoagulation System for Wastewater Treatment 3-30 kW 15 40m3/h Electrocoagulation System for Wastewater Treatment 3-30 kW 16 40m3/h Electrocoagulation System for Wastewater Treatment 3-30 kW 17

Tag:

industrial wastewater electrocoagulation system,

electrocoagulation equipment,

electrocoagulation system for wastewater treatment
